Features & Benefits
- 100% Cooling capacity at -22° F (-30° C)
- Up to 75% of Heating capacity at -22° F (-30° C)
- Inverter Compressor
- Up to 27 SEER2 cooling efficiency
- Up to 16 EER2 heating efficiency
- Sizes: 09 / 12 / 18
- Available in 208/230V
- Built-in basepan heater
- Auto-restart function
- Refrigerant leakage detection
- Extremely quiet outdoor operation, as low as 55.5 dB(A) 1
- Anti-corrosive fin coating
- 10-Year Parts Limited Warranty 2
Specifications
- Up to 27 SEER2
- Up to 16 EER2
- Up to 17.5 HSPF2
- Outdoor sound: as low as 55.5 decibels 1
- Cooling operating range -22° ~ 122° F (-30° ~ 50° C)
- Heating operating range -22° ~ 86° F (-25° ~ 30° C)
- Piping length 98 ft (30m)
- Inverter Compressor
- 0.75 – 2.0 Ton
- 208/230V
- Heavy-gauge, galvanized steel construction
- Primed and coated with a 100% coverage, baked-enamel finish in white
Efficiencies
- Up to 27 SEER2
- Up to 16 EER2
- Up to 17.5 HSPF2
Product Details
| ENERGY STAR® qualified | U.S. Environmental Protection Agency voluntary program that helps protect climate through energy efficiency |
| Up to 27 SEER2 and 16 EER2 |
SEER2SEER2 stands for Seasonal Energy Efficiency Ratio and applies to cooling efficiency for central air conditioners and heat pumps. The higher the SEER2, the greater the energy economy. EER2The Energy Efficiency Ratio (EER2) that calculates the energy the unit uses to function. It can be found by dividing a unit’s BTU output by its wattage, and the high EER2 rating means a more efficient air conditioner, so the higher the better. |
| Up to 17.5 HSPF2 |
HSPF2Heat pumps heat your home using electricity as their fuel source, and their efficiency is measured as Heating Seasonal Performance Factor (HSPF2). The higher the HSPF2, the greater the efficiency and the greater your energy savings potential. |
Documents
Categories
ductless-systems
1 Quietest size within each model group during low fan-speed operation
2 If properly registered within ninety (90) days after original installation, parts are warranted to the original purchaser for a period of 10 years. Otherwise, parts warranty is 5 years. For other applications a 7-year parts and 7-year compressor limited warranties apply. See warranty certificate for details.
